Evergrate Trench Drains
Evergrate trench drains provide a durable and attractive linear drainage solution for a wide range of applications. Our cast iron grates can divert downspout runoff from buildings to the curb, remove excess surface water from pedestrian spaces, or work as part of green infrastructure systems. Evergrate trench drains are available in 2 frame types, 4 unique grate designs, and can be fabricated to custom lengths, making them versatile enough to handle your specific project needs.
Your Seamless Streetscape Drainage Solution.
Evergrate trench drains are compatible with our curb openings and downspout boots, providing a high quality sidewalk drainage system with virtually limitless possibilities.
T-06 | 6" Trench Drains
Medium Duty.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
18.8 lbs./LF.
6” x 18” Open Area:
18.6 sq. in.
6” x 24” Open Area:
26.3 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
19.6 lbs./LF.
6” x 18” Open Area:
21.6 sq. in.
6” x 24” Open Area:
27.2 sq. in
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
19.8 lbs./LF
6” x 18” Open Area:
10.3 sq. in.
6” x 24” Open Area:
14.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
21.2 lbs./LF.
6” x 18” Open Area:
N/A
6” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
20.2 lbs./LF.
6” x 18” Open Area:
18.6 sq. in.
6” x 24” Open Area:
26.3 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
20.7 lbs./LF.
6” x 18” Open Area:
21.6 sq. in.
6” x 24” Open Area:
27.2 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
21.3 lbs./LF.
6” x 18” Open Area:
10.3 sq. in.
6” x 24” Open Area:
14.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
22.8 lbs./LF.
6” x 18” Open Area:
N/A
6” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Angle Frame
(Click on each of the drawings to learn more)
Channel Frame
Product Drawings
T-06A Metro
T-06A Continuum
T-06A Tsunami
T-06A Diamond
T-06C Metro
T-06C Continuum
T-06C Tsunami
T-06C Diamond
T-08 | 8" Trench Drains
Medium Duty.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
21.5 lbs./LF.
8” x 18” Open Area:
28.4 sq. in.
8” x 24” Open Area:
40.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
22.3 lbs./LF.
8” x 18” Open Area:
34.7 sq. in.
8” x 24” Open Area:
44.4 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
23.1 lbs./LF.
8” x 18” Open Area:
21.5 sq. in.
8” x 24” Open Area:
28.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
25.2 lbs./LF.
8” x 18” Open Area:
N/A
8” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
23.3 lbs./LF.
8” x 18” Open Area:
28.4 sq. in.
8” x 24” Open Area:
40.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
24.3 lbs./LF.
8” x 18” Open Area:
34.7 sq. in.
8” x 24” Open Area:
44.4 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
25.3 lbs./LF.
8” x 18” Open Area:
21.5 sq. in.
8” x 24” Open Area:
28.6 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A48 Class 35B Gray Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
27.2 lbs./LF.
8” x 18” Open Area:
N/A
8” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Angle Frame
(Click on each of the drawings to learn more)
Channel Frame
Product Drawings
T-08A Metro
T-08A Continuum
T-08A Tsunami
T-08A Diamond
T-08C Metro
T-08C Continuum
T-08C Tsunami
T-08C Diamond
T-12 | 12" Trench Drains
Medium Duty.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
28.2 lbs./LF.
12” x 18” Open Area:
50.0 sq. in.
12” x 24” Open Area:
68.7 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
29.3 lbs./LF.
12” x 18” Open Area:
63.2 sq. in.
12” x 24” Open Area:
80.8 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
31.5 lbs./LF.
12” x 18” Open Area:
23.6 sq. in.
12” x 24” Open Area:
32.0 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
34.5 lbs./LF.
12” x 18” Open Area:
N/A
12” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
30.2 lbs./LF.
12” x 18” Open Area:
50.0 sq. in.
12” x 24” Open Area:
68.7 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
32.5" sq. lbs./LF.
12” x 18” Open Area:
63.2 sq. in.
12” x 24” Open Area:
80.7 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
33.2 lbs./LF.
12” x 18” Open Area:
23.6 sq. in.
12” x 24” Open Area:
32.0 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
37.7 lbs./LF.
12” x 18” Open Area:
N/A
12” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Angle Frame
(Click on each of the drawings to learn more)
Channel Frame
Product Drawings
T-12A Metro
T-12A Continuum
T-12A Tsunami
T-12A Diamond
T-12C Metro
T-12C Continuum
T-12C Tsunami
T-12C Diamond
T-14 | 14" Trench Drains
Medium Duty.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Evergrate trench drain meets Load Class B, appropriate for light pneumatic tire traffic in sidewalk and pedestrian areas.
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
32.1 lbs./LF.
14” x 18” Open Area:
51.0 sq. in.
14” x 24” Open Area:
68.8 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
32 lbs./LF.
14” x 18” Open Area:
79.8 sq. in.
14” x 24” Open Area:
99.4 sq. in
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
34.6 lbs./LF.
14” x 18” Open Area:
29.9 sq. in.
14” x 24” Open Area:
48.7 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
38.3 lbs./LF.
14” x 18” Open Area:
N/A
14” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
36.4 lbs./LF.
14” x 18” Open Area:
50.0 sq. in.
14” x 24” Open Area:
68.8 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
36.3 lbs./LF.
14” x 18” Open Area:
79.0 sq. in.
14” x 24” Open Area:
99.0 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
39 lbs./LF.
14” x 18” Open Area:
29.9 sq. in.
14” x 24” Open Area:
48.7 sq. in.
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
.jpg)
Grate Material:
ASTM-A536-65-45-12 Ductile Iron
Grate Finish:
Plain or anti-skid Black Powder Coat
Frame material:
A36 Mild Steel
Frame Finish:
Plain or Hot Dip Galvanized
Grate + Frame Weight:
42.7 lbs./LF.
14” x 18” Open Area:
N/A
14” x 24” Open Area:
N/A
Load:
Class-B, ADA Compliant Grating
Recycled Content:
85%
Country of Origin:
100% Made in the USA
Angle Frame
(Click on each of the drawings to learn more)
Channel Frame
Product Drawings
T-14A Metro
T-14A Continuum
T-14A Tsunami
T-14A Diamond
T-14C Metro
T-14C Continuum
T-14C Tsunami
T-14C Diamond
Why Evergrate Trench Drains?
ADA Compliance
Our low profile grate designs conform to ADA Accessibility Guidelines for pedestrian areas.
Custom Trench Lengths
Our frame material is fabricated to length,
allowing for custom grate lengths.
Green Infrastructure Solution
Evergrate trench drains are ideal for green infrastructure and Low Impact Design (LID) applications.
Theft Resistant
Stainless steel Penta-Lock mechanism prevents theft and allows removal for maintenance.
Made in America.
Made to Last.
All Evergrate components are proudly manufactured and assembled in the USA using domestic materials of unparalleled durability.
Manufactured from
Recycled Content
All Evergrate products are manufactured using an average of approximately 85% recycled content, and 100% recyclable at the end of their life cycle.
